HSZ3.75S

Product Code: HSZ3.75S-63

Contact us about this product

Find this product near me

Documents

Technical Documents

Version 62

Comparison Chart

Model Motor Output (hp) Phase Discharge Size (in) Max Solid Diameter (in) Diameter (in) Height (in) Weight (lb)
HS2.4S 1/2 Single 2 0.276 10 1/16 12 15/16 25
HSE2.4S 1/2 Single 2 0.276 13 1/2 17 1/2 26
HSZ2.4S 1/2 Single 2 0.276 13 1/2 15 1/8 30
HS2.75S 1 Single 2 0.276 11 7/16 15 5/16 42
HSZ2.75S 1 Single 2 0.276 11 7/16 15 5/16 42
HS3.75S 1 Single 3 0.276 12 7/16 15 7/16 43
HS3.75SL 1 Single 3 0.276 12 7/16 16 3/4 50
HSZ3.75S 1 Single 3 0.276 13 1/2 17 1/2 50
HSZ3.75SL 1 Single 3 0.236 15 3/4 19 7/8 50
HSD2.55S 3/4 Single 2 0.393 10 3/8 15 3/8 39


Description

Durable trash pumps designed to pump water containing sand, solids and debris with minimal wear and clogging.

  • Built-in shaft mounted agitator suspends solids
  • Urethane semi vortex impeller for maximum durability and pump performance
  • Dual inside mechanical seal with SiC faces provides longest operational life
  • Oil Lifter (Patented) provides lubrication of the seal faces
  • V-ring seal design protects mechanical seal from abrasive particles
  • HSZ Series – Automatic / float operated version
Motor Output (HP) 1
Phase Single
Discharge Bore (in.) 3
Voltage/Amp 115/9.6
Cable Length (ft.) 32
Dimension (Dia x H, in.) 12 7/16 x 15 5/16
Continuous Running Water Level (in.) 17.5
Pump Weight (lbs.) 49
